Application field：
Food processing
Fishery processing
Meat processing
Medical scientific research
Supermarket and Logistic
Dye chemical industry
Cold accumulation project
Product feature：
Stainless steel one plate with two ice freezing surface , full production
The ice thickness 3-20mm adjustable , and fulfill to the different application
Special fow type plate design, compared with smiliar product , the refrigeration efficient is higher and more energy save.
Adapt hot refrigerant gas for ice doffing , ice doffing faster and without secondary polluation.
The evaporator is open type design, the freezing plate surface , water spray span, water channel is easy to clean.
The part contact with ice is stainless steel , it fully conforms to the certification requirement of HACCP.
Special refrigeration system design, adapted to different working condition and working stable.
Simplified structure , the move part is less and matainance is easy
The machine adapts the hot dipped galvanized steel welding structure, corrosion resistance, long service life
Full-automatic control

Working condition：
Power supply: full electric system complying with the general international standard
Stardard working condition of ice making: water supply temperature 20℃, ambient temperature 33℃
The applicable working condition: water supply temperature 0~35℃, ambient temperature 5~40℃
Refrigerant: R404A、R507A
Performance Parameter：
Capacity of ice making:15000kg/d
Evaporating temp.: -18℃, condensing temp.: 38℃
Compressor model: SRC-S-255, quantity of compressor:1 set
Compressor refrigeration capacity:114.7kw, compressor motor:100hp
COP:2.55 kW /kW, power：50.9 kW
Cooling water pump:2.2kw, cooling air fan:1.5kw
Reducer:1.5kw
cooling pump:3.7kW
Running electricity consumption:59.8kw, installation power:83.9kw
Ice making electricity consumption: 92.58kW.h/t, ice making water consumption: 631.25 l/h
Ice output dimension: 1400*130mm
Weight:5800kg
Overall dimension: L4250*W2200*H2500mm
(due to technical innovation, the parameter above will be some change, please contact our sales department if needful)
